Philips Dynalite DBC905W Signal Dimmer Controller
PH913703040009
5 Years Warranty
Free Delivery on orders over £150
| SKU | PH913703040009 |
|---|---|
| Brand | Philips |
| EAN Code | 8710163506746 |
| Manufacturer's Part Number (MPN) | 913703040009 |
| Manufacturer's Product Name | 9 x 5A EcoLinx HF Ballast Controller - 6 Way Wieland connectors |
In stock
Product Description
DBC905 Signal Dimmer Controller
Easy to install controller with flexible mounting options
The Philips Dynalite DBC905 is a nine-channel signal dimmer controller, designed for direct installation within ceiling cavities. The device incorporates structured wiring connectors to enable quick connection without the use of tools.
- Multiple protocols supported – Each control output supports DALI broadcast, DALI addressed, 1-10 V and DSI protocols.
- Integration ease – Integrates easily with a Building Management System (BMS) via the DyNet control network, making it ideally suited to commercial office installations.
- No tools required – The device is available with connectors suited to three major modular wiring brands – CMS Electracom, Wieland and Wago.
- Inbuilt diagnostic functionality – Includes lamp and driver failure, circuit run time tracking/lamp life, automated battery tests and controller online/offline status indication.
- High capacity option available – Offers increased capacity, 200 A surge switched outputs and seven DALI loads or ten 1-10 V loads per channel.
- Dimensions: 189 x 416 x 35 mm (7.44 x 16.38 x 1.38 in)
DBC905 Signal Dimmer Controller
Easy to install controller with flexible mounting options
The Philips Dynalite DBC905 is a nine-channel signal dimmer controller, designed for direct installation within ceiling cavities. The device incorporates structured wiring connectors to enable quick connection without the use of tools.
- Multiple protocols supported – Each control output supports DALI broadcast, DALI addressed, 1-10 V and DSI protocols.
- Integration ease – Integrates easily with a Building Management System (BMS) via the DyNet control network, making it ideally suited to commercial office installations.
- No tools required – The device is available with connectors suited to three major modular wiring brands – CMS Electracom, Wieland and Wago.
- Inbuilt diagnostic functionality – Includes lamp and driver failure, circuit run time tracking/lamp life, automated battery tests and controller online/offline status indication.
- High capacity option available – Offers increased capacity, 200 A surge switched outputs and seven DALI loads or ten 1-10 V loads per channel.
- Dimensions: 189 x 416 x 35 mm (7.44 x 16.38 x 1.38 in)
| SKU | PH913703040009 |
|---|---|
| Brand | Philips |
| EAN Code | 8710163506746 |
| Manufacturer's Part Number (MPN) | 913703040009 |
| Manufacturer's Product Name | 9 x 5A EcoLinx HF Ballast Controller - 6 Way Wieland connectors |
